Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE etc.
Model Number: Rogen

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Technology: Reverse Osmosis Design: Skid Mount
Permeate Flow/TPD: 10~1000 Recovery Rate: 60~90%
Feed TDS/ppm: <2,000 Water Temp.: 5~35˚C
Material: SS304/SS316L,carbon Steel Free Chlorine Mg/L: 0
Silt Density Index: <3 Dissolved Iron Mg/L: <0.1
Size: Depends,1750*550*1650mm Capacity: 0.5-110m3/h
Desalination Rate: 98%, 99% TSS/mg/L: <5
Voltage: 380V,415V,220V,can Be Customized Application: School, Restaurant, Offices
PH: 3~9 Pump: CNP / Grundfos,CNP
Type: Reverse Osmosis System Function: Water Purifying, Desalination
High Light:

2000 lph reverse osmosis water treatment system

,

odm reverse osmosis water treatment system

,

who standard ro filter system

Product Description

2000 Lph Reverse Osmosis Water Treatment System Drinking Who Standard

2000 Lph Reverse Osmosis RO Water Filter System (RO-2000LPH) for Drinking Water WHO Standard

What is reverse osmosis/RO water purifier system

Reverse osmosis is one of the most advanced technologies to purifier tap water, underground water, bore hole water, river water, sea water, brackish water in the world. It can remove more then 97% of deliquescent saline substance and 99% of colloid, microbe, particulate and organic substance in water. It is widely used in foodstuff, pharmaceutical, chemical industry, electronic industry for terminal process. It is a key for water filter equipment.



Parameter

Model: RO-4000
Production capacity:4000 Liters per hour
Total power:About 6.6KW
Raw water pump:SS304 1 set Nanfang
Quartz sand filter, carbon filter:φ900×1900mm, FRP or SS304
Security filter:30″×5μm ,9 core , SS304
High-pressure pump :SS304 1 set Nanfang
RO membrane:Membrane BW30-400IG 4 PCS USA DOW
Membrane housing:8040 ,4 pcs , FRP
Quartz sand:1000kg

Activated carbon:300kg
Size:7500X1500X2800mm
Certificate:CE&ISO
Warranty:One year
Payment:T/T or West union(30% deposit in advance,70% blance pay before delivery)

The process of RO water treatment

Raw water-- Raw water tank --Raw water pump --Quartz sand filter-- Active carbon filter-- Security filter-- high pressure pump-- RO systemPure water tank-- UV/Ozone --Pure Wate

2000 Lph Reverse Osmosis Water Treatment System Drinking Who Standard 0

Function of every parts
1). Raw water pump-- provide the pressure to quartz sand filter/active carbon filter
2). Quartz filter-- get rid of turbidity, suspended matter, organic matter, colloid, etc.
3). Active Carbon filter--Remove the color, free chloride, organic matter, harmful matter, etc.
4). Water Softener--using ion exchange resin to exchange "ions" of calcium and magnesium is the most common and the easiest method of removing hardness of water and render the water suitable for utility purpose
5). Security filter--It is also called cartridge Filter, prevent any deposition of large Particles, most of the bacteria, and viruses into the UF membrane and RO membrane, The accuracy is 5um, for holding back any large particulates such as large iron, dust, suspended matter, impurity.
6). High pressure pump-- The high pressure pump is used for make sure there are enough water for satisfying designed production capacity.
7). RO (reverse osmosis) system--RO system is the main part of pure water treatment plant. The RO membrane's desalt rate can reach as high as 99%, it is capable of removing over 99% of ions, bacteria, particles and 98% of organic

Application field:

1). Electronics
2). Power system
3). Metallurgical industry
4). Chemical industry
5). Medical and pharmaceutical industry
6). Foods and beverage industry
7). Treatment of industrial sewage and waste water
8). Brackish water desalination etc

The feather of RO water equipment

1). Can production water continuously and highly automatic
2). No need the chemical regeneration, easy operation
3). RO system choose the import USA DOW membrane
4). Automatic switch on when low water level, and switch off when high water level
5). RO membrane can backwash automatic and reduce thepollution.
6). Water shortage protection for multi-stage pump
7). Porduction water condutivity meter can test the monitoring quality on line contionuosly.
8). Low operation Cost and Long life span
9). It is PC program controller
10). Easily control and Maintained.
11). Auto membrane flushing
12). Environmental protection, Low power consumption
13) Auto flush/backwash
14) Low /high pressure protection



Operation Specifications

Max. feed water temperature: 42°C
Equipment upgrade for TDS up to 5,000 ppm
Hydrogen Sulfide must be removed
Max. Silica tolerance: 25 ppm @ 60% recovery
Feed water TDS: 0-2,000 ppm
Operating pressure: 150 to 250 psi
pH tolerance range: 3-11
Max. Iron content: 0.05 ppm
Feed water pressure: 20 to 80 psi
Hardness over 1 GPG requires water softener
Turbidity should be removed
Operate at higher TDS by lowering recovery



Technical Specification

Model Number Permeate Flow Rate Membranes Motor Rating at 1,000 ppm Approx. Weight Dimensions
GPD M3/D Size Qty. 60Hz (hp) 50Hz (hp) LBS KG L”xW”xH” LxWXH (cm)
ROS-1125 600 2 2.5"x40" 1 1/2 1/2 100 45 21x24x55 53x61x140
ROS-2125 1,200 5 2.5"x40" 2 1/2 1/2 110 50 21x24x55 53x61x140
ROS-3125 1,800 7 2.5"x40" 3 3/4 3/4 125 57 21x24x55 53x61x140
ROS-1140 1,500 6 4"x40" 1 1 1 125 57 21x25x55 53x64x140
ROS-2140 3,000 11 4"x40" 2 1 1 160 73 21x25x55 53x64x140
ROS-3140 4,500 17 4"x40" 3 1.5 1.5 190 86 21x25x55 53x64x140
ROS-4140 6,000 23 4"x40" 4 1.5 1.5 220 100 21x30x55 53x76x140
ROS-5140 7,500 28 4"x40" 5 2 2 250 114 21x30x55 53x76x140
ROS-6140 9,000 34 4"x40" 6 2 2 280 127 21x30x55 53x76x140
ROS-8140 12,000 45 4"x40" 8 3 3 380 173 27x34x56 69x86x142
ROS-10140 15,000 57 4"x40” 10 3 3 450 205 27x34x56 69x86x142
ROS-12140 18,000 68 4"x40” 12 3 3 500 227 27x40x56 69x102x142



Voltage Codes:

116 = 115v, 1ph, 60hz (up to ROS-2140 only)

215 = 220/230v, 1ph, 50hz

216 = 220/230v, 1ph, 60hz

235 = 240v, 3ph, 50hz (ROS-3140+ Only)

236 = 240v, 3ph, 60hz (ROS-3140+ Only)

335 = 380v, 3ph, 50hz (ROS-3140+ Only)

435 = 400/415v, 3ph, 50hz (ROS-3140+ Only)

436 = 460v, 3ph, 60hz (ROS-3140+ Only)

2000 Lph Reverse Osmosis Water Treatment System Drinking Who Standard 1

2000 Lph Reverse Osmosis Water Treatment System Drinking Who Standard 2



2000 Lph Reverse Osmosis Water Treatment System Drinking Who Standard 3

Desalination Rate
96%-98%
Recovery Rate
50%-75%
Motive Force
Environmental Protection, Water Treatment
Ca2+ & Mg2+
Softener Filter
Material
Full Stainless Steel 304
Control
Manual & Automatic
Disinfection
UV Sterilizer / Ozone Generator
Weight
650kg
Voltage
110V/ 220V/380V
Frequency
50Hz / 60Hz
Power
2.5 Kw
Warranty
1 Year
Trademark
FG
Transport Package
Wooden Case
Specification
2000X670X1700mm
Origin
Guangzhou, China
HS Code
8421219990
