4TPH 25200GPD Reverse Osmosis Water Treatment System

4TPH 25200GPD Reverse Osmosis Water Treatment System

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: RO-4TPH, 1-17

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Permeate Flow: 4,000L/h, 25200GPD Design: Skid Mount
Recovery Rate: 60~65% Feed TDS/ppm: <2,000
Water Temp.: 5~35˚C Material: SS304/SS316L,carbon Steel
Voltage: 380V,415V,220V,can Be Customized Desalination Rate: 99%,99.7%
Control: Electronic,Manual/PLC Ro Membrane: Vontron, Hydranautics Or DOW,4040
High Light:

25200GPD Reverse Osmosis Water Treatment System

,

4TPH Reverse Osmosis Water Treatment System

,

SS304 industrial ro water system

Product Description

4TPH 25200GPD Reverse Osmosis Water Treatment System

4 ton per day reverse osmosis drinking industrial water treatment plant 25200GPD



Reverse Osmosis(RO) is a process that uses semi-permeable spiral wound membranes to separate and remove dissolved solids, organic,pyrogens,submicron colloidal matter,color,nitrate and bacteria from water. Feed water is delivered under pressure through the semi-permeable membrane,where water permeates the minute pores of the membrane and is delivered as purified water called permeate water.Impurities in the water are concentrated in the reject stream and flushed to the drain is called concentrate water.

Flow Chart

raw water - raw water tank - raw water pump - sand filter - carbon filter - softener (optional) - security filter - high
pressure pump - reverse osmosis system - water tank -booster pump-reverse osmosis system-pure water tank- UV sterilizer / ozone generator (optional) - water supply points

Model
RO-4000L
Production capacity
4000 L/Hr
Power
5.0Kw
Power supply
3P 380V 50Hz/1P 220V 50HZ/1P 220V 60HZ
Reverse osmosis (RO)membrane
USA DOW/VONTRON
Membrane housing
8080 SS
Raw water pump
CNP
Quartz sand filter, activated Carbon filter,water softener
FRP 3pcs
Security filter
Stainless steel with 5um PP filter
High pressure pump
CNP

 4TPH 25200GPD Reverse Osmosis Water Treatment System 0

4TPH 25200GPD Reverse Osmosis Water Treatment System 1
