12000LPH Automatic Aqua Pure Reverse Osmosis System

12000LPH Automatic Aqua Pure Reverse Osmosis System

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: RO-12TPH, 1-14

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Permeate Flow: 12,000L/h Design: Skid Mount
Recovery Rate: 65~75% Feed TDS/ppm: <2,000
Water Temp.: 5~35˚C Material: SS304/SS316L,carbon Steel
Voltage: 380V,415V,220V,can Be Customized Desalination Rate: 99%,99.7%
Control: Electronic,Manual/PLC Ro Membrane: Vontron, Hydranautics Or DOW,4040
High Light:

12000LPH aqua pure reverse osmosis system

,

415V aqua pure reverse osmosis system

,

SS316L reverse osmosis equipment

Product Description

12000LPH Automatic Aqua Pure Reverse Osmosis System

12000L/h Automatic Aqua Mineral Bottled Water Borehole Well Salty Water Treatment System



RO water purifier machine is to help to change such as seawater, brackish water,underground water and tap water act...into direct drinking water, bottle water, industrial water,mineral water,alkaline water atc...



Reverse osmosis system it can remove particle, colloid, organic impurity, heavy metal ion, bacteria, virus in water, and it can also remove 99% dissolved salt.



Flow Chart

raw water - raw water tank - raw water pump - sand filter - carbon filter - softener (optional) - security filter - high
pressure pump - reverse osmosis system - water tank -booster pump-reverse osmosis system-pure water tank- UV sterilizer / ozone generator (optional) - water supply points

NO.
Name
Function
Remark
1
Raw water tank
Store water ensure to supply water stably and continuously for whole system
Customer provide for themselves, because big size will result in expensive freight.
2
Raw water pump or called booster pump
Provide needed pressure for every pretreatment filter
We can provide CNP pumps or Grundfos

pumps
3
Mechanical filter /quartz sand filter /sand filter
We use fiber glass or stainless steel vessel as housing, fill quarts sand, it can filter big particles impurities, suspended substances, colloids
etc.

4
Activated carbon filter
We use fiber glass or stainless steel vessel as housing, fill activated carbon, remove color, odor, residual chlorine and organics substances.


5
Security filter /pp filter / sediment filter
Prevent large particles, bacteria, viruses into RO membrane, accuracy is 5 micron

6
High pressure

pump

 Provide needed working pressure for RO system, ensure production capacity of pure water.

CNP pump, Grundfos

optional
7
RO(reverse osmosis) system
Can remove particles, colloids, organic impurities, heavy metal ions, bacteria, virus, heat source etc. harmful substances and 97% dissolved salts.
RO membranes USA

Filmtec Dow,VONTRON
8
UV/Ozone generator
Kill bacterials in water. UV for direct drinking water. Ozone generator for bottle water




12000LPH Automatic Aqua Pure Reverse Osmosis System 0

12000LPH Automatic Aqua Pure Reverse Osmosis System 1

12000LPH Automatic Aqua Pure Reverse Osmosis System 2

12000LPH Automatic Aqua Pure Reverse Osmosis System 3
