5 Liters Water Treatment Consumables IX Resin Semiconductor
Product Details:
| Place of Origin: | China |
| Brand Name: | ZG |
| Certification: | CE/NSF etc. |
| Model Number: | WTC-12 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 bag |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export PP Bag |
| Delivery Time: | 15~30 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 10,000 bags per month |
|
Detail Information |
|||
| Max Operating Temperature: | 120 ºC | PH Range: | 0-14 |
|---|---|---|---|
| Particle Size: | 600-800μm | Regenerant: | 4-10% HCl, 1-8% H2SO4, NaCl |
| High Light: | 5L Water Treatment Consumables,800um mixed bed resin,5L mixed bed resin |
||
Product Description
5 Liters Water Treatment Consumables IX Resin Semiconductor
ZGER8420 electronic-grade hybrid resin semiconductor EDI electrophoresis polishing resin 5 liters
Mixed Bed (MB) ion exchange units can provide treated water with excellent quality, though are not typically designed for efficiency in terms of regenerant consumption. Their use should therefore, mostly be reserved for waters having a low salinity, which will result in a long service cycle length.
The practical limits for the use of a MB unit are approximately: l Salinity < 1 meq/L (50 mg/L as CaCO3 ) l TDS < 100 mg/L l Conductivity < 100 µS/cm
In the electronics industry, from the cleaning of various electronic components to the preparation of a series of process solutions, high-quality pure water is required, especially for the production of semiconductor devices and large-scale integrated circuits. Ultra-pure water is used in almost every process. Water cleaning. The important role of ultrapure water in the electronics industry has become increasingly prominent, and it has become one of the important factors affecting the quality and production costs of electronic components.
Ion exchange resin is suitable for the treatment of water with low ion content. It can completely remove ions in the water, especially suitable for the polishing stage of ultrapure water. This is also one of the reasons why ion exchange resin has strong vitality.
| Application | Recommended Products | Main uses and characteristics |
| High purity, low TOC, electronic grade polishing resin | ZGER8410 ZGER8415 ZGER8420 |
Specially used in the preparation of ultra-pure water in special electronic industries, such as the production of disk drives, display devices, CD-ROMs, independent semiconductor devices, low-density integrated circuits, or the production of ultra-pure water in the sub-block and accessory operations of subsequent integrated circuits , The effluent water can reach 17MΩ.cm in the first operation, and the TOC content of the effluent water is less than 5ppb when the TOC of the influent is less than 20ppb. In addition, the high-precision post-processing and high-level regeneration of Zhengguang electronic-grade hybrid resin can also be applied to other general ultrapure water manufacturing industries. It has the characteristics of rapid rise in effluent water quality, stable effluent resistivity, large water volume per unit volume, stable operation performance, etc. |
| High purity, low TOC, electronic grade polishing resin | Low TOC series ZGER8410LT ZGER8415LT ZGER8420LT |
Specially used in the preparation of ultra-pure water in special electronic industries, such as the production of disk drives, display devices, CD-ROMs, independent semiconductor devices, low-density integrated circuits, or the production of ultra-pure water in the sub-block and accessory operations of subsequent integrated circuits , The effluent water can reach 17MΩ.cm in the first operation, and the TOC content of the effluent water is less than 5ppb when the TOC of the influent is less than 20ppb. In addition, the high-precision post-processing and high-level regeneration of Zhengguang electronic-grade hybrid resin can also be applied to other general ultrapure water manufacturing industries. It has the characteristics of rapid rise in effluent water quality, stable effluent resistivity, large water volume per unit volume, stable operation performance, etc. |
| EDI special resin | ZGC108-EDI ZGA307-EDI |
It is suitable for the mixed bed system of EDI electric regeneration module . As long as the water treatment design is reasonable, it can produce high-purity silicon-free desalinated water with resistivity above 15MΩ·cm. It has good penetration resistance, strong oxidation resistance, and extremely fast exchange speed. Features such as high mechanical strength. |
| EDI special resin | ZGC650-EDI ZGA550-EDI |
A homogeneous resin , suitable for mixed bed systems for EDI electric regeneration modules , as long as the water treatment design is reasonable, it can produce high-purity silicon-free desalinated water with a resistivity of 17MΩ·cm or more, with good penetration resistance and strong oxidation resistance , Extremely fast exchange speed and high mechanical strength. |
| ZG C ER 50 strong acid cation resin | Preparation and purification of ultrapure water in the electronics industry. | |
| ZG C ER 80 Macroporous Strong Acidic Cationic Resin | Preparation and purification of ultrapure water in the electronics industry. | |
| ZG A ER 140 strong alkaline anion resin | Preparation and purification of ultrapure water in the electronics industry. | |
| ZG A ER 170 strong alkaline anion resin | Preparation and purification of ultrapure water in the electronics industry. | |
| ZG A ER 210 Macroporous strong alkaline anion resin | Preparation and purification of ultrapure water in the electronics industry. | |
| ZG ER 8710 electronic grade mixed bed resin | The preparation and refinement of ultrapure water in the electronics industry can produce high-purity silicon-free desalinated water with a resistivity greater than 15MΩ•cm. |
