4kW 50Hz 36000GPD Purified Water Treatment System

4kW 50Hz 36000GPD Purified Water Treatment System

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: WTS-19

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 200 set per month
Get Best Price Contact Now

Detail Information

Technology: Pretreatment+Reverse Osmosis/UF/NF Etc. Design: Skid Mount/Containerised
Permeate Flow/TPD: 0.25~1000 Water Temp.: 5~35˚C
TSS/mg/L: <5 Silt Density Index: <3
Warranty: 1 Year Voltage: 380V,415V,220V,can Be Customized
Application: Water Purification,Filtration,pharmceutical,drinking Water,food Type: Water Treatment Plant System
Function: Water Purifying, Filtration, Desalination Desalination Rate: 99%,99.7%
Control: Electronic,Manual/PLC Ro Membrane: Vontron, Hydranautics Or DOW, 4040/8040
High Light:

36000GPD Purified Water Treatment System

,

4kw Purified Water Treatment System

,

36000GPD waste water purification system

Product Description

4kW 50Hz 36000GPD Purified Water Treatment System

Market sectors of process water production and wastewater treatment  & purification system



We help companies in industrial markets optimize their process water production and employ efficient wastewater treatment technologies. This potentially includes the option to recycle their plant water for re-use, providing an ongoing source of cost-effective feed water, ultimately contributing to lower production costs.



Typical markets industrial water treatment solutions

  • Automotive plants
  • Food and beverage
  • Mining
  • Petrochemical
  • Pharmaceutical
  • Power plants
  • Pulp and paper
  • Steel processing

Key automotive plant water treatment technologies include:

Our technology for automotive plant water treatment solutions include:



  • Microfiltration
  • Reverse osmosis
  • Ultrafiltration



Key food and beverage water treatment technologies include:

We provides a number of technologies for treating water used in the beverage and food industries. Each provides technological solutions for the various stages of water treatment that are required in the food & bev industry.



  • Clarification: helps remove suspended solids and particulate matter - usually with the help of flocculants and coagulants, which improve settling.
  • Filtration: used for the physical, mechanical and biological separation of solids from treated water.
  • Membrane filtration: feed water is forced through a semi-permeable membrane at high pressure to separate specific materials from the solution.
  • Softening: water softening involves removing calcium, magnesium and other metal cations using ion exchange resins.
  • Deionisation: used for water softening, either cationic or anionic ion-exchange.
  • Reverse osmosis: uses membrane separation like membrane filtration.
  • Process water polishing: Exceptional solids removal process. It is used for phosphorous removal and water reuse, as well as treating wet weather flows.
  • Disinfection with water treatment chemicals and UV: Destroys disease-causing organisms to prevent their spread. Processes such as ozonation and ultraviolet irradiation also aid in the destruction of biological contaminants that remain in the water after treatment.
  • Biological treatment: helps upgrade the quality of beverage and food industry effluent being released into the environment and a major component in water recycling from high organic load wastewater.

ROM series Reverse Osmosis Specifications



Model Number Permeate Flow Rate Pressure Vessel 8" Membranes Motor Rating at 1,000 ppm Approx. Weight Dimensions
GPD M3/D Qty. Qty. 60Hz (hp) 50Hz (kw) LBS KG L”xW”xH” LxWXH (cm)
ROM-1480 28,000 109 1 4 5 4 2300 1045 170x33x58 432x84x147
ROM-1580 36,000 136 1 5 7.5 4 2350 1068 210x33x58 533x84x147
ROM-1680 43,000 164 1 6 7.5 5.5 2400 1091 250x36x58 635x91x147
ROM-2480 57,000 218 2 8 7.5 7.5 2500 1136 170x36x58 432x91x147
ROM-2580 72,000 273 2 10 10 7.5 2600 1182 210x36x58 533x91x147
ROM-3480 87,000 327 3 12 15 11 2700 1227 170x48x66 432x122x168
ROM-3580 108,000 409 3 15 20 15 3200 1455 210x48x66 533x122x168
ROM-3680 130,000 491 3 18 20 15 3500 1591 250x62x66 635x157x168
ROM-4580 144,000 545 4 20 20 15 4200 1909 210x62x66 533x157x168
ROM-4680 173,000 655 4 24 20 18.5 4550 2068 250x62x66 635x157x168

MINE PROCESS WATER AND WASTEWATER TREATMENT



Water solutions have successfully helped mining companies across the globe to refine minerals, reduce waste, limit pollution, and drive profitability.



Pre-treatment technology:

  • Groundwater, surface water, grey water treatment
  • Seawater desalination
  • Pipeline design and supply
  • Process water re-use



Leach liquor filtration technology:

  • Precious metals and minerals can be recovered from leach streams and other process water



Process mine water treatment technology:

  • Removal of pollutants such as heavy metals, suspended solids, arsenic, cyanide, iron, selenium, chromium, manganese, and various others.
  • Moving towards zero liquid discharge



Tailings pond management technology:

  • Dewatering and drying
  • Water recovery and re-use
  • Discharge legislation compliance
  • Positive mine water balance control and management



Complete range of mine water treatment technologies:

  • Biological Processes
  • Desalination
  • Clarification
  • Evaporation & Crystallisation
  • Disinfection
  • Filtration
  • Ion Exchange
  • Membrane Separation
  • Package Plants
  • Sludge Treatment & Handling



WATER SOLUTIONS FOR DOWNSTREAM OIL & GAS APPLICATIONS

We offer a complete range of technologies to ensure a secure, safe and reliable water supply, including seawater RO desalination; raw water pretreatment; and process water production, utility water and demineralised water.



Downstream oil & gas processes generate wastewater that requires treatment prior to discharge or reuse. Pollutants such as oils and hydrocarbons, hydrogen sulphide, ammonia, phenols, COD, BOD, mercury, selenium, cyanides and chlorides must be removed to ensure full compliance and appropriate quality.

We provide the full spectrum of wastewater treatment for downstream oil & gas:

  • Oil/water separation
  • Biological treatment
  • Tertiary treatment
  • Sludge treatment
  • Dissolved and dispersed hydrocarbons removal
  • Insoluble hydrocarbons removal



By reusing and recycling water from your effluent treatment plant in downstream operations, companies can significantly lower their water costs, ensure regulatory compliance and minimise environmental impact.



Pharmaceutical water treatment technologies

Key water treatment technologies from Veolia that are tailored for the pharmaceutical industry include:



  • Multimedia filters
  • Activated carbon filters
  • Softening
  • Reverse osmosis (RO)
  • Continuous deionizing





Power plant water treatment systems

We provide various types of treatment systems tailored for use with power plants. These are:

  • Pre-treatment systems
    Remove suspended solids, colloidals, organics, iron, and manganese from water
  • Boiler feed water systems
    Reduce impurities entering boiler feed systems, preventing deposition and scaling
  • Condensate polishing plants
    Reduce suspended solids, iron and ionic impurities that cause corrosion and downtime
  • Cooling tower blowdown treatment plants
    Reduce corrosion in blowdown systems and discharge cleaner water into environment
  • Flue gas desulphurisation plants
    Remove heavy metals, gypsum and other particles
  • Recycling and re-use
    Treat and recycle water within a power plant, reduce plant discharges and raw water intake

KEY POWER PLANT WATER TREATMENT TECHNOLOGIES INCLUDE:

Veolia provides numerous key technologies designed for industry. The following key technologies are ideal for use with power plant water treatment solutions:

  • Filtration
  • Reverse osmosis (RO)
  • Demineralisation
  • Continuous electro-deionisation (CEDI)
  • Combined pre-treatment (RO and CEDI)
  • Mixed bed ion exchange
  • Water treatment chemicals



ENGINEERING VALUE ACROSS THE PULP AND PAPER WATER CYCLE

We offer technologies for all aspects of pulp and paper water management within the facility. Our expertise in pulp and paper water treatment reduces water cycle costs and optimizes water consumption per ton of pulp and paper produced.



The pulp and paper industry deals with effluent offering wide potential in reuse and recycling. Plants making the best use of their wastewater significantly lower their production costs. Processes like anaerobic digestion are ideal for pulp and paper wastewater treatment to stabilize sludge and produce biogas for renewable energy.



Influent water

Optimise influent water usage to improve plant efficiency and equipment and process performance. We use these technologies to treat the influent water of a paper mill:

  • Dissolved air flotation
  • Clarification
  • Sand filters and other media filtration
  • Discfilters



Boiler feed water

Get maximum energy efficiency from your plant’s boilers while reducing any power supply issues to ensure plant uptime.

Boiler feed:

  • Reverse osmosis
  • CEDI
  • Mixed beds
  • Ion exchange resins

Condensate polishing:

  • Mixed beds with regeneration system



Cooling water

Ensure efficient heat transfer, reduce plant maintenance and ensure plant uptime by controlling scaling within cooling systems, including ink cooling circuits. We optimise cooling water with:

  • Clarification
  • Filters, softening
  • Membrane treatment
  • Water treatment chemicals



Wastewater, reuse & sludge treatment

Reuse reduces potable water requirements and provides a consistent, quality and dependable source of process water. Wastewater generated by the paper recycling processes also needs specific treatment before being discharged or recycled to be re-used by plants.



We can help reduce sludge volumes and improve sludge conditioning, opening a whole range of reuse/disposal possibilities to benefit your operation.



Key steel processing water treatment technologies

The key technologies from Veolia for steel processing water treatment include:



  • Clarification
    DAF, Lamella etc.

  • Media filtration
    Used to remove remaining suspended particles and unsettled floc using a variety of drum, disk, gravity and pressurised filters.

  • Reverse osmosis

Otherwise called membrane separation, Veolia uses a ‘family’ of membrane processes classified as microfiltration, ultrafiltration, nanofiltration and reverse osmosis.



Our water technologies are suitable for all your unique water needs and locations:

  • Potable Water Treatment Plants
  • Sewage Treatment Plant
  • Mobile Treatment Plants
