380GPD Sea Water Reverse Osmosis Desalination System

380GPD Sea Water Reverse Osmosis Desalination System

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/UL/NSF etc.
Model Number: SWRO4-380GPD~10,000GPD

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Technology: Reverse Osmosis Design: Skid Mount
Permeate Flow/TPD: 1.4~38 Permeate Flow/GPD: 380~10,000GPD
Recovery Rate: 8~35% Feed TDS/ppm: <35,000
Water Temp.: 5~35˚C PH: 4~9
TSS/mg/L: <5 Silt Density Index: <3
Free Chlorine Mg/L: 0 Dissolved Iron Mg/L: <0.1
Warranty: 1 Year Material: SS304/SS316L,carbon Steel
Capacity: 0.5-100m3/h Voltage: 380V,415V,220V,can Be Customized
Application: Water Purification,Filtration,pharmceutical,drinking Water,food Size: Depends,1750*550*1650mm
Type: Seawater Reverse Osmosis System Function: Water Purifying, Desalination
Desalination Rate: 99%,99.7% Control: Electronic,Manual/PLC
Ro Membrane: Hydranautics Or DOW,4040 Pump: Danfoss/CAT/CNP
High Light:

380GPD Reverse Osmosis Desalination System

,

99.7% Reverse Osmosis Desalination System

,

380GPD seawater RO system

Product Description

380GPD Sea Water Reverse Osmosis Desalination System

Sea water reverse osmosis system SWRO4 skid mount DOW filmtec 380 GPD to 10,000 GPD



Seawater desalination utilizes permeable membranes, which are only tasked to remove dissolved solids while dividing the feed water into purified water and the rejected concentrated salts. The salts and other organics are thrown into the brine stream then flushed into a drain. At the end we have purified water that has 99% less dissolved salts. These seawater reverse osmosis systems are immensely powerful, with the capacity of purifying significantly high TDS water.



Seawater RO systems are usable anywhere from yachts to municipalities. It’s important to choose the correct materials of construction to handle seawater (which is highly corrosive). We use materials such as SS316L, Duplex SS 2205, SS 2207, and SS 904 to guarantee a longer operating life and less maintenance.



Commercial SWRO-C is equipped with premium components which include duplex SS centrifugal-type high pressure pump for high performance and corrosion resistance, a programmable computer controller with many built-in features, 1000 psi fiberglass membrane housings for durability and US made seawater membranes for high quality product water.



Our SWRO4 Series is available with capacities ranging from 380 GPD to 10,000 GPD and a maximum feed water TDS of 45,000 ppm. We offer standard units as well as customizable to fit you water application needs.



In choosing the correct SWRO model, the following information must be provided:

  • Flow rate (GPD, m3/day, etc.)
  • Feed water TDS or sea source (ex: Pacific, Mediterranean, etc.)
  • Seawater Source (open intake or beach well)
  • Iron, manganese, and hydrogen sulfide must be removed before the water enters the reverse osmosis unit
  • TSS must be removed before commercial SWC system
  • Turbidity should be removed
  • SDI must be less than 3
  • Water should be free from oil and grease
  • Chlorine must be removed
  • Available voltage, phase, and frequency
  • Dimensions of proposed area where commercial SWC System will be installed

Operation Specifications



Feed water TDS: 10,000-42,000 ppm
Operating pressure: 700 to 1,000 psi
pH tolerance range: 3-11
Max. feed water temperature: 42°C
Feed TDS up to 50,000 ppm
H2S, turbidity and organics must be removed
Feed water pressure: 40 to 80 psi
Antiscalant dosing is required
Max. Iron content: 0.05 ppm

Technical Specification

Model No. Permeate Membranes Motor HP Approx Weight. Dimensions
at 1000 ppm
GPD M3/Day Size Qty 60 HZ 50 HZ LBS. KG L”xW”xH” LxWXH (cm)
SWRO4-125 380 1.4 2.5" x 40" 1 2 2 220 100 51X21X30 130X53X76
SWRO4-225 700 2.7 2.5" x 40" 2 2 3 230 105 51X21X30 130X53X76
SWRO4-325 1,000 3.8 2.5" x 40" 3 3 3 250 114 51X21X30 130X53X76
SWRO4-425 1,300 5 2.5" x 40" 4 3 3 290 132 51X21X30 130X53X76
SWRO4-104 1,100 4 4" x 40" 1 5 5 395 180 61X34X50 155X86X127
SWRO4-204 2,100 8 4" x 40" 2 7.5 7.5 500 227 61X34X50 155X86X127
SWRO4-304 3,000 11 4" x 40" 3 7.5 7.5 360 164 61X34X50 155X86X127
SWRO4-404 3,800 14 4" x 40" 4 7.5 7.5 500 227 61X34X50 155X86X127
SWRO4-504 4,700 18 4" x 40" 5 10 10 750 341 61X34X50 155X86X127
SWRO4-604 5,600 21 4" x 40" 6 10 10 850 386 61X34X50 155X86X127
SWRO4-704 6,000 23 4" x 40" 7 10 10 970 441 61X34X50 155X86X127
SWRO4-804 7,600 29 4" x 40" 8 15 15 1,050 477 61X34X50 155X86X127
SWRO4-1004 10,000 37.9 4" x 40" 10 15 15 1,150 523 61X34X50 155X86X127



Standard Features: Available Options:
Low & high pressure switches
Permeate TDS monitor
Stainless steel high pressure piping
Stainless steel throttling valve for reject stream
Powder coated steel frame
Heavy duty 5 micron cartridge prefilter
Seawater resistant SS pump
Microprocessor/PLC based control panel & VFD
Glycerin-filled 316 SS prefilter pressure gauges
Product & reject flow meters
TFC spiral wound membranes
FRP membrane housings
380-415V/3Ph/50Hz power supply
Automatic feed shut off valve
Chemical dosing systems
Media and Iron prefiltration systems
Ozonation and UV sterilization systems
Post deionization polishers
Remote monitor / control option
Product tank level controller switch
Feed pH controller with sensor
Feed ORP controller with sensor
Water and hour meters
Feed water conductivity monitor
Membrane cleaning skid
Automatic hourly flush
Feed/Permeate blending
Explosion proof RO
Export crating
Containerized / mobile seawater RO
460V/3Ph/60Hz power supply



Ideal applications for a Reverse Osmosis Water Maker include:
Cargo Ships
Coastal Developments
Hotels & Resorts
Seaside Work Sites
Seaside Villas
Work Boats
Fish Processing Plants
Boat, Yacht and Sailboat
Oil Tankers
Island-Based Businesses
Villages & Cities



380GPD Sea Water Reverse Osmosis Desalination System 0

More information about SWRO

What is seawater reverse osmosis?

Seawater reverse osmosis systems are designed to decline more than 99% of saline compromised within the feed water. These systems also incorporate a rinsing, chemical purifying apparatus to eliminate sodium chloride, avert scaling, and preserve system performance. There are two fundamental elements within every seawater reverse osmosis system, which are reverse osmosis membranes and high pressure feed pumps. These elements make up the center of any reverse osmosis system and need special consideration and application for successful operation.



Does reverse osmosis remove salt from seawater?

Yes, semipermeable membranes enable the feed water to pass through it at a much higher volume than dissolved salts. Reverse osmosis systems work by applying pressure as freshwater streams through its membranes to filter out the concentrated saline in the feed water, as well as minerals and pollutants. These unwanted impurities are either flushed away, recycled, or processed. Seawater reverse osmosis systems utilize more than one membrane to boost the load of purified water turned out each day.



What are the advantages of desalination plants?

Seawater desalination has become a vital alternative to the production of pure freshwater throughout the areas of the world without drinkable water. As other sources such as rivers, lakes, wells, and springs have become more exhausted due to excessive extraction, the ocean has provided an abundant supply of available water for human use. Although ocean water consists of elevated levels of salt, and therefore is unable to be utilized for consumption or most other purposes, seawater desalination has helped make it practical.
