30000GPD Brackish Water Reverse Osmosis , Commercial Reverse Osmosis Water System

30000GPD Brackish Water Reverse Osmosis , Commercial Reverse Osmosis Water System

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/UL/NSF etc.
Model Number: BWRO4-11

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Technology: Brackish Water Reverse Osmosis Permeate: 30000~180000GPD
Feed TDS/ppm: <10,000 Water Temp.: 5~35˚C
PH: 4~9 TSS/mg/L: <5
Silt Density Index: <3 Material: SS304/SS316L,carbon Steel
Voltage: 380V,415V,220V,can Be Customized Application: Water Purification,Filtration,pharmceutical,drinking Water,food
Control: Electronic,Manual/PLC Ro Membrane: Hydranautics Or DOW,4040
High Light:

30000GPD Brackish Water Reverse Osmosis

,

380V Brackish Water Reverse Osmosis

,

30000GPD commercial reverse osmosis water system

Product Description

30000GPD Brackish Water Reverse Osmosis , Commercial Reverse Osmosis Water System

30000~180000GPD Containerized Borehole Highly Brackish Water RO Purification Systems

Description

Reverse osmosis process uses semi permeable spiral wound membranes to separate and remove dissolved solids, organic, pyrogens, sub micron colloidal matter and bacteria from water. Feed water is delivered under a pressure of approximately 16 kg/cm2 through reverse osmosis membranes. Waterpermeates the minute pores of the membrane and is delivered as purified water. Impurities in the water are concentrated in the reject stream and flushed to drain. Reverse osmosis is capable of removing 90-99% of total dissolved solids (TDS), 99% of organic, including pyrogens, and 99% bacterials in the feed water.



Parameters

Feed Source
Tap
Water
Well
Water
Surface Water
Brackish
Water
Feed SDI   <3 <3 <5 <5
Max Element Recovery (%)   19 17 15 13
Average System Flux (gfd)   20 17 13 10
Max Feed Flow Rate per Element (gpm) 2.5" Diameter 6 6 6 6
Max Feed Flow Rate per Element (gpm) 4" Diameter 14 14 14 14
Max Feed Flow Rate per Element (gpm) 8" Diameter 75 70 55 60
Min Concantrate Flow Rate per Element (gpm) 2.5" Diameter 1 1 1 1
Min Concantrate Flow Rate per Element (gpm) 4" Diameter 3 3 3 3
Min Concantrate Flow Rate per Element (gpm) 8" Diameter 14 14 14 14



This system's design is depend on customer raw water test report and application.



Processing

Raw water→ raw water tank(buyer supply)raw water pump→laminated filter →activated carbon filter→chemical dosing system→security filter→high pressure pump→ro system→water supply point



Some parts function:

Quartz sand filter: fill quarts sand inside, it can filter big particles impurities, suspended substances, colloids etc.
Activated carbon filter: fill activated carbon inside, to remove color, odor, residual chlorine and organics substances.
Security filter: fill PP filter cartridge inside, prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um.
Chemical dosing system: add antiscalant(buyer supply) , absorb Ca2+, Mg2+(main elements for composing scale), reduce hardness of raw water.
RO membrane: can remove particles, colloids, organic impurities, heavy metal ions, bacteria, virus, heat source etc. harmful substances and 99% dissolved salts.
UV sterilizer: for killing bacterial in water, be safe for drinking.
CIP system: its help to cleaning the RO membrane, so that it can be have long life span^^



Application

• Homes and Villas
• Hotels/Hospitals
• Commercial Complexes
• Kindney Dialysis Unit
• Poultry Farms
• Food and beverages industry
