GAC Multimedia Filter Water Treatment , Granular Activated Carbon Water Filter

GAC Multimedia Filter Water Treatment , Granular Activated Carbon Water Filter

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: MFS-XZ

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film/Containerized
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 200 set per month
Get Best Price Contact Now

Detail Information

Technology: Pressurized Filtration Material: Carbon Steel/FRP/stainless Steel
Design: Skid Mount/containerized Water Temp.: 5~35˚C
Water Flow Rate: Up To 1,000 M3/day.vessel Voltage: 380V,415V,220V,can Be Customized
Application: Surface, Underground Water, Sewage Water Treatment Size: Dia.20cm~180cm
High Light:

GAC Multimedia Filter Water Treatment

,

OEM Multimedia Filter Water Treatment

,

FRP granular activated carbon water filter

Product Description

GAC Multimedia Filter Water Treatment , Granular Activated Carbon Water Filter

China Supplier High Quality Cheap Activated Carbon Filter FRP Tank

Commercial Activated Carbon Water Filters

Commercial Granular Activated Carbon Water Filters ( GAC ) are designed for outstanding performance, and are ideal for removing chlorine, organics, chloramines, colours, odour, THMs and Volatile Organic Compounds ( VOCs ) from water. They are cost effective and reliable.



Our Commercial GAC Activated Carbon Water Filters are available in a range of different types of activated carbon which are matched with the application and also types of contaminants that need to be removed:

  • Granular coconut shell activated carbon
  • Bituminous activated carbon
  • Silver impregnated bacteriostatic activated carbon
  • Catalytic activated carbon
Model
Port
Diameter
*
Height
(mm)
Upper
opening
Lower
opening
Upper
water
distribution
Lower
water distribution
Central tube
844
Top loading
205*1130
2.5" screw thread
/
N0801
N0801-A
6 point
1035
Top loading
250*890
2.6" screw thread
/
N0802
N0802-A
7 point
1054
Top loading
250*1370
2.5" screw thread
/
N0801
N0801-A
6 point
1252
Top loading
300*1320
2.5" screw thread
/
N0802
N0807
1"
1354
Top loading
330*1370
2.5" screw thread
/
N0802
N0807
1"
1465
Top loading
360*1650
2.5" screw thread
/
X2801-A
X2811
1"
1665
Top loading
400*1650
2.5" screw thread
/
X2801-A
X2811
1"
1665
Top loading
400*1650
4" screw thread
/
N182B
ES6260A1
1.5"
1865
Top loading
450*1650
4" screw thread
/
N182B
ES6370A1
1.5"
2169
Side loading
530*1750
4" screw thread
4" screw thread
E5671C
EF6370A1
1.5"
2472
Side loading
600*1850
4" screw thread
4" screw thread
E5671C
EF6450A1
/
3072
Side loading
750*1850
4" screw thread
4" screw thread
E5671C
EF6600A1
/
3672
Side loading
900*1850
4" screw thread
4" screw thread
E5671C
EF6700A1
/
4072
Side loading
1000*1850
4" screw thread
4" screw thread
E5671C
EF6700A1
/
4894
Side loading
1200*2400
6" Flange
6" Flange
S416
EF5674
/
6094
Side loading
1500*2400
6" Flange
6" Flange
S416
EF5675
/
7296
Side loading
1750*2400
6" Flange
6" Flange
S417
EF5676
/
8096
Side loading
2000*2400
6" Flange
6" Flange
S417
EF5676
/

GAC Activated Carbon Water Filters features:

  • Comes with standard Clack electronic control valve. A mechanical control valve is available on demand
  • Heavy duty structural tanks – Poly Glass mineral tank
  • All brass, motor driven control valve with fully adjustable regeneration cycles (on units with electronic control valve)
  • Self adjusting backwash control (on units with electronic control valve)
  • Flow controller to limit backwash flow
  • Engineered for commercial and industrial use
  • Optional skid mounting for tanks



Activated charcoal is used in water filters, medicines that selectively remove toxins, and chemical purification processes. In the production of steam-activated charcoal, first the coconut shell or coal is heated to create a char. This char is then “activated” in a furnace at high temperatures of 1,700° to 1,800°F with steam in the absence of oxygen. In the steam-activation process, all volatile compounds are removed, and at the same time layer after layer of carbon atoms are pealed off, enlarging the existing internal pores, and leaving behind a carbon skeleton. The carbon + steam reaction results in producing hydrogen gas and carbon monoxide (C+H2O=H2 +CO). As the carbon monoxide gases off it takes carbon atoms with it. Typically 3 pounds of raw charcoal will produce 1 pound of activated charcoal.



Chemical-activation produces the same end result – a much increased internal surface area – but uses a chemical solution to chew away the internal structure. Typically wood-based activated charcoals are commercially made using heat (450–900 °C)and phosphoric acid. This “activation” process results in the creation of an enormous surface area — on the order of 600 to 1,200 square meters per gram (m2/g), depending upon the raw material used and the process.



The treatment results in a highly porous charcoal. These tiny holes give the charcoal a surface area of 300-2,000 m2/g, allowing liquids or gases to pass through the charcoal and interact with the exposed carbon. The carbon adsorbs a wide range of impurities and contaminants, including chlorine, odours, and pigments. Other substances, like sodium, fluoride, and nitrates, are not as attracted to the carbon and are not filtered out. Because adsorption works by chemically binding the impurities to the carbon, the active sites in the charcoal eventually become filled. Activated charcoal filters become less effective with use and have to be recharged or replaced. Organics are typically removed by adsorption and residual disinfectants by catalytic reduction .



What are the benefits of activated carbon?

  • Highly effective at removing non-polar organic chemicals from water.
  • Our activated carbon is the only activated carbon on the market incorporating Poly-silsesquioxane with durable antimicrobial properties.
  • Applicable to a wide variety of organic compounds
  • Very effective at removing colours from waste streams.
  • Effective at removing low levels (ppb range) of inorganic pollutants.
  • Thermal regeneration of the carbon destroys the adsorbed waste solute.
  • Very flexible system allows rapid start-up and shut down as needed.
  • System can be designed so that it is portable, to be taken to waste sites.

Limitations of Activated Carbon Treatment

  • Limited to wastes with low organic concentrations (< 5%).
  • Limited to wastes with very low inorganic concentrations (< 1%).
  • Unable to remove highly soluble organics, or those with low molecular weights.
  • Systems can not tolerate suspended solids in the influent stream (due to clogging).
  • Does not effectively remove chloramines.
  • Adsorption efficiency is related to residence time and condition of carbon bed.
