50Hz Water Treatment Spare Parts , CDL Vertical Multistage Centrifugal Pump
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal/OEM |
| Certification: | CE/NSF etc. |
| Model Number: | CDL/CDLF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Wood Crate/Carton or Naked wrapped by film/Containerized |
| Delivery Time: | 15~30 days |
| Payment Terms: | T/T, Western Union, Paypal etc. |
| Supply Ability: | 10,000 set per month |
|
Detail Information |
|||
| Type: | Multistage Water Pump | Material: | SS304/SS316L |
|---|---|---|---|
| Design: | Skid Mount/containerized | Water Temp.: | 5~35˚C |
| Element: | 1-8/vessel | Voltage: | 380V,415V,220V,can Be Customized |
| Flow: | Dia.2.5"/4"/8" | Configuration: | High Pressure, Booster |
| High Light: | CDL Water Treatment Spare Parts,50Hz vertical multistage centrifugal pump,CDL vertical multistage centrifugal pump |
||
Product Description
50Hz Water Treatment Spare Parts , CDL Vertical Multistage Centrifugal Pump
CDL Vertical Multistage Centrifugal Pump, 50Hz High Pressure Water Pump for water treatment
CDL Series is a sheet metal Stainless Steel Vertical Multistage Centrifugal Pumps offered by CNP. The pumps are driven by standard electrical face mounted motor up to 7.50 kW and flange mounted for ratings higher than 7.5 kW. CDL Series pumps are available with Inlet-Outlet and pump head in cast iron material. Pumps are available in single Phase as well as three Phase.
Major Applications :-
- High Pressure Boiler Feed
- Water Supply for Boilers
- Used in Condensation Systems
- Cooling and Air Conditioning System (HVAC)
- Water Treatment and Reverse Osmosis Systems
- In Water Softening Systems
- Industrial Cleaning Systems
- Pressure Booster in Municipal Water Supply
- Pressure Boosters for High Rise Buildings
- Drip Irrigation and Sprinkler Systems
- High Pressure Water Transfer
- Fire Fighting Systems(Jockey Pump)
- Clear Liquid Transfer in Water Treatment Projects
- High Pressure Pump requirements in Cement, Paper & Pulp, Steel, Textile, Rubber and Plastic Industries.
- Pump for Windmill Cooling Systems.
- High Pressure Pump requirements in Oil, Gas & Fertiliser Industry
- In Power plants
- Induction Heating
- High Pressure Industrial Washing
- In Manufacturing Processes
- For Curing
- For Industrial Cooling
- In Cooling Tower
Key Features :-
Our Vertical Multi Stage Centrifugal Pump is reliable and service-friendly, Space-saving, suitable for slightly aggressive liquids energy efficient.
Close coupled vertical multistage pump with stainless steel parts which be driven by a standard TEFC motor, discharge and suction in the same line.
Single phase motor up to 2.2 kW, Class F and IP55 are available.
Standard supply for liquid temperature up to 700, high temperature pumps are available on request.
Mechanical seal is Tungsten Carbide/Graphite, other material is available on request
60 Hz pumps are also available on request, please confirm performance curve before selection.
Performance Range :-
| Flow Range (Q) | 0.4-240.0 m³/hr |
| Delivery Head | Max. 305 mtr (30.5 Bar) |
| Liquid Temperature | -15 °C~ + 70 °C |
| MOC | SS-304 with Inlet and Outlet in CI |
| Speed (n) | 2900rpm |
| Power (P) | Upto 110 kW |
Applications
The CDL, CDLF multistage in-line centrifugal pumpsare designed for the following applications:
Municipal water supply and pressure boosting
Domestic water supply
Boiler feed and condensate systems
Cooling water systems
Irrigation and dewatering
Fire fighting
Washing plants and Washdown
Water treatment plants
Reserve Osmosis systems
