7GPM Electrodeionization EDI Water Purification System
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal/OEM |
| Certification: | CE/NSF etc. |
| Model Number: | IX-3A-5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Wood Crate/Carton or Naked wrapped by film/Containerized |
| Delivery Time: | 15~30 days |
| Payment Terms: | T/T, Western Union, Paypal etc. |
| Supply Ability: | 200 set per month |
|
Detail Information |
|||
| Technology: | Pressurized Filtration | Material: | Carbon Steel/FRP/stainless Steel |
|---|---|---|---|
| Design: | Skid Mount/containerized | Water Temp.: | 5~35˚C |
| Water Flow Rate: | Up To 200 M3/day.vessel | Voltage: | 380V,415V,220V,can Be Customized |
| Application: | Surface, Underground Water, Sewage Water Treatment | Size: | Dia.20cm~180cm |
| Control: | Electronic,Manual/PLC | ||
| High Light: | 7GPM edi water purification system,OEM 7GPM edi water purification system,7GPM OEM electrodeionization water treatment |
||
Product Description
7GPM Electrodeionization EDI Water Purification System
Ion exchange electro-deionization EDI water purification system for Power Generation, Pharmaceutical, Semiconductor 1GP~7GPM
EDI-Series Electrodeionization Systems are a superior option to conventional mixed-bed deionization. Ultrapure water is processed by taking reverse osmosis permeate water and feeding it into the EDI System which uses electricity to continuously drive ions through deionization resins and ion selective membranes, thus producing a small concentrate stream.
These EDI systems do not require regeneration and there are no chemicals used for operation. EDI-Series Electrodeionization Systems are available in four flow ranges up to 7 gallons per minute (GPM). These systems feature a modular design, so they can be easily expanded to accommodate various requirements. Additionally, systems can be arranged in parallel for increased capacities.
| Models | EDI – 001 | EDI – 003 | EDI – 005 | EDI – 007 |
| Design | ||||
| Nominal Capacity (gpm / lpm) | 1 / 3.8 | 3 / 11.3 | 5 / 18.9 | 7 / 26.5 |
| Operating Pressure Nominal – Maximum (psi / bar) |
40 – 75 / 3 – 5 | 40 – 75 / 3 – 5 | 40 – 75 / 3 – 5 | 40 – 75 / 3 – 5 |
| Nominal Discharge Concentrate + Electrode (gpm / lpm) |
0.10 / 0.38 | 0.3 / 1.14 | 0.5 / 1.9 | 0.7 / 2.65 |
| Nominal Recovery % | 90 | 90 | 90 | 90 |
| Feed Water Specifications | ||||
| Feed Conductivity 1 | Optimum FCE <9µS/cm Max FCE 33µS/cm | |||
| Total CO2 + HCO3 | < 5 mgn CO2 + HCO3· (Optimum < 2 mg/l CO2 + HCO3) | |||
| Hardness | < 1.0 ppm @ 90% recovery (ask about higher hardness) | |||
| Organics | < 0.5 ppm TOC | |||
| Metals | < 10 ppb | |||
| Feed Temp | Optimum: 15° C – 30° C Range: (5° C – 35° C) | |||
| Feed pH | Optimum: 7.0 – 7.5 Range: 5.0 – 9.5 | |||
| Feed Chlorine | ND | |||
| Silica, SiO2 | < 0.5 ppm | |||
| System Component Specifications | ||||
| Pressure Gauge | At Filter Outlet: Stainless Steel Case, Bronze Internals. Glycerin–filled | |||
| Pressure Regulator | Nickel Plated Bronze 3/4”. Set at 40 psi (2.7 bar) | |||
| Piping | 3/4” PVC, Schedule 80 | |||
| Valves | Inlet Isolation Ball Valve, 2 Sample Valves | |||
| Flow Control | Product, Concentrate & Electrode Flow Control Orifices | |||
| Switches | Off/On Switch, Feed Low Pressure Cut–out, Concentrate Low Flow Cut–out | |||
| Filters | 5 Micron Prefilter, 4.5” x 10” | |||
| Concentrate | 1/2” QC | |||
| Feed / Product | 3/4” FNPT | |||
| Product Quality | 2 MΩ Dl Quality Indicator with Red – Green Indicator & Alarm Typical Product Quality: 5 – 18.2 MΩ *Depends on FCE1 of RO Permeate |
|||
| System Electrical | ||||
| Power Usage – Nominal | 200W | 300W | 400W | 600W |
| Power Usage – Maximum | .8kW | 1.5kW | 1.6kW | 1.5kW |
| Electrical Input | 178 – 264 VAC, 50/60Hz, 1 – Phase, FLA 20A | |||
| Systems Dimensions | ||||
| Approximate Dimensions* L x W x H (in / cm) | 25.75 x 25.75 x 60 / 65.41 x 65.41 x 152.40 |
25.75 x 25.75 x 60 / 65.41 x 65.41 x 152.40 |
25.75 x 25.75 x 60 / 65.41 x 65.41 x 152.40 |
25.75 x 25.75 x 60 / 65.41 x 65.41 x 152.40 |
| Approximate Weight (lbs / kg) | 125 / 56 | 137 / 62 | 145 / 66 | 161 / 73 |
