Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: IX-2A

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film/Containerized
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 200 set per month
Get Best Price Contact Now

Detail Information

Technology: Pressurized Filtration Material: Carbon Steel/FRP/stainless Steel
Design: Skid Mount/containerized Water Temp.: 5~35˚C
Water Flow Rate: Up To 200 M3/day.vessel Voltage: 380V,415V,220V,can Be Customized
Application: Surface, Underground Water, Sewage Water Treatment Size: Dia.20cm~180cm
Control: Electronic,Manual/PLC
High Light:

450000 Grain 180cm Ion Exchange Water Purification System

,

180cm Ion Exchange Water Purification Systems

,

180cm 450000 Grain mixed bed deionizers

Product Description

450000 Grain Ion Exchange Water Purification System , Mixed Bed Deionizers

Mixed Bed Deionizers MBDI ion exchange purification water filters 62,000 to 450,000 grains

Ion Exchange can be defined as a reversible exchange of ions between a solid (resin) and a liquid containing dissolved ions. Mineral salts are comprised of cations and anions. Since deionization requires the removal of all ions, both the negatively charged anions and positively charged cations, minerals capable of attracting both are required. These materials are known as anion and cation exchange resins.



Deionizers are fixed bed systems in which ion exchange resins are contained in pressure vessels. The water is then forced through the resin. After a service run, the resin becomes exhausted and unable to remove additional ions so it must be regenerated with strong acid and base solutions to restore its ion exchange capacity.



Model #

Nominal

Capacity

Service Flow

Rate (GPM)

Pipe

Size

Mineral

Tank Size

Resin Qty.
Average Peak Cation Anion
MB18 62,000 18 27 2" 18"x108" 2.5 3
MB24 112,000 31 47 2" 24"x108" 4.5 5.5
MB30 170,000 50 75 2" 30"x108" 7 8.5
MB36 250,000 70 105 2" 36"x108" 10 12.25
MB42 350,000 100 145 3" 42"x108" 14 17.25
MB48 450,000 125 190 3" 48"x108" 18 22.25



Standard Features: Available Options:
  • Automatic or Semi-automatic operation. Automatic regeneration when water quality falls below pre-set limit or after manual initiation.
  • Constant monitoring of water quality
  • Solid-state reliability PLC control for trouble-free service
  • No untreated by-pass water
  • Alternate regeneration water source piping - standard
  • Automatic shut down in the event of power failure
  • Two-stage air mix standard
  • Compact, non-corrosive components
  • Steel tanks with rubber lining
  • Convenient, modular construction
  • Easy, economical installation
  • Optional recirculation pumps
  • Simultaneous regeneration and chemical displacement
  • Brine kill option available for high purity systems
  • Programmable purge prior to regeneration
  • 12 volt operation (120V/60hz/1pH transformer included)
  • Regeneration chemical tanks (hydrochloric acid & sodium hydroxide)
  • Insulated/heated clearwell
  • Drain neutralization system making it possible to discharge chemicals into sewer network
  • Heating system for sodium hydroxide
  • Air compressor
  • Sound or light alarms for end-of-cycle notifications
  • Brine kill for high purity systems
  • 220V/1P



Deionizers are often used in applications requiring very high water quality, usually as polishers after reverse osmosis. Many industries use DI systems:
  • Paint
  • Chemicals
  • Electronics
  • Textiles
  • Plating
  • Electro deposition
  • Printing
  • Testing and materials
  • Research and development
  • Glassware rinse
  • Hospitals/Medical facilities
  • Vehicle washes
  • Film processing
  • Ice plants
  • Horticulture/Greenhouse
  • Food/Beverage processing
  • Cosmetics
  • Metalworking lubricants
  • Glass/Mirror
  • Boiler feed
  • Humidification control
